MODENAS KRISS MR2

MODENAS KRISS MR2

Carrying a single-cylinder, 110 cc, air-cooled power plant, fed by carburettor, the Modenas Kriss MR2 produces approximately 8.3 hp at 7,500 rpm and 8.2 Nm of torque at 5,500 rpm. Power gets to the ground via a four-speed centrifugal clutch gearbox, rolling on 17-inch wheels.

Fuel for the MR2 is carried in a 4.5-litre tank located under the seat, where a 6.6 litre cubby storage compartment can also be found. The space will fit a half-shell helmet, folded raincoat or other miscellaneous small items.

Features
  • Display Screen
  • Electric side mirror
  • LED Head Lamp
  • Pass Switch
  • Shutter Lock
  • Side Reflectors
  • Sports package
Engine
Cylinder 2-stroke, single cylinder
Displacement 109.2 cm³
Bore x Stroke 50.0 mm x 55.6 mm
Compression Ratio 8.8:1
Maximum Horsepower 8.2hp (7,500rpm)
Maximum Torque 8.2Nm (5,500rpm)
Starting System Electric and Kick
Lubrication System Wet Sump
Fuel Tank Capacity 4.5 L
Carburetor PZ19
Ignition System Magneto to CDI
Tranmission
Transmission Type Rotary Type 4-Speed
Primary Reduction Ratio 4.058
Secondary Reduction Ratio 2.643
Clutch Type Multiple Disc, Centrifugal and Wet
Chasis
Frame Type Pipe Backbone, Steel Pipe
Overall Length 1,900 mm
Overall Width 685 mm
Seat Height 760 mm
Dry Weight 94.5 kg
Brakes
Front and Rear Hydraulic Single Disc and Drum
Suspension
Front Suspension Type Telescopic
Rear Suspension Type Trailing Swingarm, Arm Suspension
